150W 36V 4.3A 80-305VAC/100-430VDC Switching Power Supply
0 reviews - Write a review
C$21.87
  • In Stock: Pre-order
  • Brand: MORNSUN
  • Model: LM150-23B36R2
  • Gross Weight: 0.29kg
  • Certificated: ISO, CE
Sold: 1

Click country for real-time stock

Add to Cart
Question
Add to Wish List Compare this Product
What Does Pre-order Mean?
A pre-order product is an item not currently in stock. When you place your order, we will begin production or procurement specifically for your purchase.

Specifications

  • Part No.: LM150-23B36R2
  • Power(W): 154.8
  • Vin(VAC): 80 - 305
  • Vin(VDC): 100 - 430
  • Vout(VDC): 36V
  • Iout: 4.3A
  • Efficiency(%): 91.5
  • Isolation Voltage: 4000VAC
Electrical Specification
Efficiency(%) 91
Max. Output Current(A) 4.3
Power Supply Specification
Input Voltage(VAC/VDC) 80 - 305/100 - 430
Output Voltage(VDC) 36
PFC Function No
Power(W) 154.8
Physical Specification
Inventory Method Shared Inventory
File Size
LM150-23B36R2 Manual 2.86MB Download
