7" 800x480px RS-485 Serial port 128MB/FLASH 64MB/Memory HMI Touch Screen LED Display

Discontinued

7" 800x480px RS-485 Serial port 128MB/FLASH 64MB/Memory HMI Touch Screen LED Display

0 reviews - Write a review

C$0.00

In Stock: 1
Model: HI1073
Gross Weight: 3.70kg
Certificated: ISO

Qty

Add to Cart

Question

Add to Wish List Compare this Product

This product has a minimum quantity of 999

How to Choose a Shipping Warehouse？

For customers in the US, the UK, EU, Australia and Russia, please prioritize selecting a local warehouse. For the EU countries, choose the German warehouse.
The benefits of this selection include faster delivery times and lower overall costs, as no customs duties are incurred.

This cost-effective HMI touch screen features a 7-inch LED display with a resolution of 800x480px and a brightness of 250cd/m², with a backlit LED display for easy viewing. The service life of the backlight is more than 20,000 hours. The panel complies with IP65 standards for flat screens. It has low power consumption, high running speed and stable performance. It is mainly used for various PLCs or intelligent controllers with communication ports. Through the simple, convenient and powerful software, users can master the design methods and quickly create programs.

Specifications

Part Number: HI1073
Display Type: HMI Display
Processor: 4-core high-performance CPU
Storage: 128MB NAND FLASH + 64MB Memory
Operating Voltage: 24VDC
Display Resolution: 800x480px
Display Brightness: 250cd/m²
Display Backlight: LED
Display Size: 7"
Panel Cut-out: 192.0x138.0mm
Backlight Lifetime: 20,000 hours
USB Port: USB TYPE-C
Ethernet: No
I/O Port: COM(RS-232,RS-422/RS-485)

Downloads

Electrical Specification
Has Ethernet?	No
Has IIoT?	No
Operating Voltage(V)	24
WIFI Enabled	No
Physical Specification
Backlight Lifetime(h)	20000
Display Brightness(cd/m²)	250
Display Resolution(Pixels)	800x480
Display Size(inch)	7
Panel Cut-out(mm)	192.0x138.0
Processor	4-core high-performance CPU
Storage	128MB NAND FLASH + 64MB Memory
