DRA-40-12 MEANWELL 40.08W 12VDC 3.34A 115/230VAC Single Output Switching Power Supply
0 reviews - Write a review
C$31.45
5 + C$30.53
10 + C$29.67
50 + C$28.85
100 + C$28.08
  • In Stock: Pre-order
  • Brand: MEANWELL
  • Model: DRA-40-12
  • Gross Weight: 0.30kg
  • Certificated: ISO, CE, RoHS

Available Options

Add to Cart
Question
Add to Wish List Compare this Product
What Does Pre-order Mean?
A pre-order product is an item not currently in stock. When you place your order, we will begin production or procurement specifically for your purchase.
How to Choose a Shipping Warehouse？
For customers in the US, the UK, EU, Australia and Russia, please prioritize selecting a local warehouse. For the EU countries, choose the German warehouse.
The benefits of this selection include faster delivery times and lower overall costs, as no customs duties are incurred.
Ships within 24 hours!
Ships within 24 hours basically means that your product will be shipped out or dispatched from our warehouse within 24 hours if it has enough stock. Read more.

This is a 40.08W 12VDC 3.34A power supply. MEAN WELL DRA-40 is one 40W AC/DC DIN rail power supply, featuring the adjustable output current. Users are able to easily change the constant output current level, via 1 ~1 OVdc, PWM signal or resistance. DRA-40 can be mounted on DIN rail TS-35/7.5 or 15; in addition, the width of the unit is only 40mm that it is well suited for the installation in a limited spacing. DRA-40 accepts the universal AC input between 90VAC and 264VAC; the efficiency is up to 87% that the entire series can operate, under free air convection, from -30°C through 70°C


Features

  • Brand MEANWELL
  • 12V DC 3.34A output
  • AC input voltage range: 90 ~ 264VAC
  • Rated power: 40.08W
  • Universal AC input/Full range
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Cooling by free air convection
  • Can be installed on DIN rail TS-35/7.5 or 15
  • UL 508 (industrial control equipment) approved
  • BS EN/EN61000-6-2(BS EN/EN50082-2) industrial immunity level
  • 100% full load burn-in test
  • 2 years warranty

Applications

  • Industrial automation machinery
  • Industrial control system
  • Mechanical and electrical equipment
  • Electronic instruments, equipments or apparatus
  • Household appliances
Electrical Specification
Efficiency(%) 85%
Max. Output Current(A) 3.34
Power Supply Specification
Brand MEANWELL
Dim.(LxWxH)(mm) 40 x 90 x 100
Input Frequency(Hz) 47 - 63
Input Voltage(VAC/VDC) 90 - 264 / 127 - 370
Output Voltage(VDC) 12
PFC Function No
Power Type DIN Rail Power Supply
Power(W) 40.08
Physical Specification
Inventory Method Shared Inventory
File Size
DRA-40.pdf 346.57KB Download
