DRDN40-12 MEANWELL 12VDC 40A DIN Rail Type Redundancy Module

Name: DRDN40-12 | DRDN40-12 MEANWELL 12VDC 40A DIN Rail Type Redundancy Module | StepperOnline CA
Brand: MEANWELL
SKU: DRDN40-12
Price: 33.48 EUR
Availability: PreOrder

DRDN40-12 MEANWELL 12VDC 40A DIN Rail Type Redundancy Module - DRDN40-12 | StepperOnline CA

DRDN40-12 MEANWELL 12VDC 40A DIN Rail Type Redundancy Module

0 reviews - Write a review

€33.48

5 + €32.51

10 + €31.58

50 + €30.71

100 + €29.88

In Stock: Pre-order
Brand: MEANWELL
Model: DRDN40-12
Gross Weight: 0.50kg
Certificated: ISO, CE, RoHS

Sold: 0

Click country for real-time stock

Ships from

China

Qty

Add to Cart

Question

Add to Wish List Compare this Product

What Does Pre-order Mean?

A pre-order product is an item not currently in stock. When you place your order, we will begin production or procurement specifically for your purchase.

Features

Support 1+1 and N+1 redundancy system

Input Voltage 12V

2 channels input and 1 output

Suitable for redundancy operation of 12V/24V/48V system

Output current up to 40A

Cooling by free a r convection

-40~+80t℃ ultra-wide operating temperature ( >+60tC derating)

55mm slim width

Built-in 2 channels DC OK signal and alarm relay contact

3 years warranty

Applications

Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
Household appliances

Electrical Specification
Efficiency(%)	98%
Max. Output Current(A)	40
Power Supply Specification
Brand	MEANWELL
Dim.(LxWxH)(mm)	55 x 125.2 x 100
Output Voltage(VDC)	12
PFC Function	No
Power Type	DIN Rail Power Supply
Physical Specification
Inventory Method	Shared Inventory
