1. GV Horizontal Type Plate 3-Phase(Brake) Motor
_motor.svg)
Note: 18* Belongs to B-type flange
2. GV Horizontal Type High Ratio Type Plate 3-Phase(Brake) Motor
_motor.svg)
3. GV Horizontal Type Plate 1-Phase(Brake) Motor
_motor.svg)
Note: 18* Belongs to B-type flange
This GV series vertical medium-sized geared motor with brake, featuring a wide reduction ratio range of 3 to 1800, power output of 100 to 3700W, and output shaft diameters from 18 to 50mm. This motor delivers smooth transmission, high load capacity, and superior efficiency with a lifespan of up to 7,000 hours, which make it ideal for industrial production, construction machinery, and marine applications that require vertical installation.
1. Motor output torque for gear ratios between 3-200
Ratio |
Output RPM |
Output Torque(kgf.m) |
||||||||||||||
0.1KW 1/8HP |
0.2KW 1/4HP |
0.4KW 1/2HP |
0.75KW 1HP |
1.5KW 2HP |
2.2KW 3HP |
3.7KW 5HP |
||||||||||
Hz |
||||||||||||||||
50 |
60 |
50 |
60 |
50 |
60 |
50 |
60 |
50 |
60 |
50 |
60 |
50 |
60 |
50 |
60 |
|
3 |
500 |
600 |
0.19 |
0.16 |
0.37 |
0.31 |
0.70 |
0.60 |
1.30 |
1.10 |
2.60 |
2.20 |
3.80 |
3.20 |
6.00 |
5.50 |
5 |
300 |
360 |
0.31 |
0.26 |
0.62 |
0.52 |
1.20 |
1.00 |
2.20 |
1.90 |
4.50 |
3.80 |
6.72 |
5.60 |
11.00 |
10.00 |
10 |
150 |
180 |
0.62 |
0.52 |
1.24 |
1.04 |
2.40 |
2.00 |
4.50 |
3.80 |
9.10 |
7.60 |
13.70 |
11.20 |
22.00 |
20.00 |
15 |
100 |
120 |
0.91 |
0.76 |
1.80 |
1.50 |
3.60 |
3.00 |
6.80 |
5.70 |
13.50 |
11.30 |
20.10 |
16.80 |
32.60 |
29.80 |
20 |
75 |
90 |
1.20 |
1.00 |
2.40 |
2.00 |
4.80 |
4.00 |
9.00 |
7.50 |
18.10 |
15.10 |
26.80 |
22.40 |
43.60 |
36.00 |
25 |
60 |
72 |
1.40 |
1.20 |
3.00 |
2.50 |
6.00 |
5.00 |
11.20 |
9.40 |
22.60 |
18.90 |
33.60 |
28.00 |
53.90 |
49.53 |
30 |
50 |
60 |
1.80 |
1.50 |
3.60 |
3.00 |
7.20 |
6.00 |
13.50 |
11.30 |
27.10 |
22.60 |
40.30 |
33.60 |
64.70 |
58.80 |
40 |
37 |
45 |
2.20 |
1.90 |
4.60 |
3.90 |
9.30 |
7.80 |
17.50 |
14.60 |
34.90 |
29.10 |
52.00 |
43.40 |
86.30 |
78.40 |
45 |
33 |
40 |
2.70 |
2.20 |
5.40 |
4.40 |
10.90 |
9.10 |
20.60 |
17.00 |
41.10 |
34.00 |
59.80 |
49.60 |
98.50 |
81.70 |
50 |
30 |
36 |
2.80 |
2.40 |
5.70 |
4.80 |
11.60 |
9.70 |
21.90 |
18.30 |
43.60 |
36.40 |
65.10 |
54.30 |
107.00 |
97.00 |
60 |
25 |
30 |
3.40 |
2.90 |
6.90 |
5.80 |
13.90 |
11.60 |
26.20 |
21.90 |
52.40 |
43.70 |
78.10 |
65.10 |
127.00 |
115.00 |
70 |
21 |
25 |
4.30 |
3.60 |
8.00 |
6.80 |
16.20 |
13.50 |
31.50 |
26.30 |
62.40 |
52.00 |
92.50 |
77.10 |
||
80 |
19 |
23 |
4.80 |
4.00 |
9.20 |
7.70 |
18.40 |
15.40 |
35.50 |
29.60 |
70.80 |
59.00 |
105.00 |
87.50 |
||
90 |
17 |
20 |
5.20 |
4.40 |
10.30 |
8.60 |
20.70 |
17.30 |
39.30 |
32.80 |
77.10 |
64.30 |
113.00 |
94.30 |
||
100 |
15 |
18 |
5.80 |
4.90 |
11.50 |
9.60 |
23.00 |
19.20 |
43.20 |
36.00 |
83.70 |
69.80 |
126.00 |
105.00 |
||
120 |
12 |
15 |
6.90 |
5.80 |
13.80 |
11.50 |
27.70 |
23.10 |
51.80 |
43.20 |
101.00 |
83.70 |
||||
140 |
11 |
13 |
8.00 |
6.70 |
16.00 |
13.40 |
32.00 |
26.70 |
59.70 |
19.80 |
116.00 |
96.80 |
||||
160 |
9 |
11 |
9.10 |
7.60 |
18.30 |
15.30 |
36.30 |
30.30 |
68.00 |
56.70 |
132.00 |
110.00 |
||||
180 |
8 |
10 |
10.3 |
8.60 |
20.70 |
17.30 |
40.80 |
34.00 |
76.80 |
64.00 |
148.00 |
123.00 |
||||
200 |
7 |
9 |
11.60 |
9.70 |
22.90 |
19.10 |
43.20 |
36.00 |
82.80 |
69.00 |
||||||
2. GV medium speed reduction motor naming rule
3. Universal size
STEPPERONLINE medium-sized geared motors support versatile customization. You can select the most suitable motor for your application based on the following parameters.
- Output Shaft Diameter:
Optioanl: 18mm, 22mm, 28mm, 32mm, 40mm, 50mm
- Motor Power:
Optioanl: 100W, 200W, 400W, 750W, 1500W, 2200W, 3700W
- Gear Ratio:
Optioanl: 3, 5, 10, 15, 20, 25, 30, 40, 45, 50, 60, 70, 80, 90, 100, 120, 140, 160, 180, 200, 250-1800
- Operating Voltage:
S: 220V/380V 3PH
B: 220V 1PH
- Direction of Junction box:
G1: Left(standard)
G2: Right
G3: Up
G4: Down
- Inlet Direction:
Optioanl: LD, LT, RD, RT, TL, TR, DL, DR, LF, LB, RF, RB, TF, TB, DF, DB
Note:
T: UP
B: BACK
D: DOWN
L: LEFT
F: FORWARD
R: RIGHT
- Air Hold Direction
