Name: HSS Series Harmonic Drive Gearbox Φ79mm Ratio 50:1 Backlash 20arcsec 8mm Input Diameter
Brand: STEPPERONLINE
SKU: HSS-17-50-I-D8
Price: 355.92 CAD
Availability: PreOrder

HSS Series Harmonic Drive Gearbox Φ79mm Ratio 50:1 Backlash 20arcsec 8mm Input Diameter - HSS-17-50-I-D8 | StepperOnline CA

Pre-order

HSS-17-50-I-D8

Frame Size(mm)Φ79

Gear Ratio(xx:1)50

Input Shaft Diameter(mm)8

Gearbox Length(mm)39

Question

Downloads

Harmonic_Gearbox_User_Manual.pdfPDF · 1.69MB HSS-17-50-I-D8_Full_Datasheet.pdfPDF · 189.04KB

Same series

Model	Frame Size(mm)	Gear Ratio(xx:1)	Input Shaft Diameter(mm)	Gearbox Length(mm)	Price	Stock
HSS-14-100-I-D8	Φ73	100	8	36	C$322.03	Backorder
HSS-14-50-I-D8	Φ73	50	8	36	C$322.03	Backorder
HSS-17-100-I-D8	Φ79	100	8	39	C$355.92	Backorder
HSS-17-50-I-D8	Φ79	50	8	39	C$355.92	Backorder
HSS-20-100-I-D14	Φ93	100	14	41	C$372.87	Backorder
HSS-20-50-I-D14	Φ93	50	14	41	C$372.87	Backorder
HSS-25-100-I-D14	Φ107	100	14	49	C$389.82	Backorder
HSS-25-50-I-D14	Φ107	50	14	49	C$389.82	Backorder
HSS-32-100-I-D19	Φ138	100	19	60	C$457.62	Backorder
HSS-32-50-I-D19	Φ138	50	19	60	C$457.62	Backorder
HSS-40-100-I-D19	Φ160	100	19	70.5	C$627.10	Backorder
HSS-40-50-I-D19	Φ160	50	19	70.5	C$627.10	Backorder

HSS Series Harmonic Drive Gearbox Φ79mm Ratio 50:1 Backlash 20arcsec 8mm Input Diameter

This harmonic gearbox has a gear ratio of 50, a frame size of Φ79mm and an input shaft diameter of 8... Read More

0 reviews • Write a review

from

C$355.92

5 + C$343.75

10 + C$332.38

50 + C$321.76

100 + C$311.78

Click country for real-time stock

Ships from

China

Qty

Add to Cart

Add to Wish List Compare this Product

Easy Returns

Return within 30 days of delivery. Contact us first and we'll take it from there.

This harmonic gearbox has a gear ratio of 50, a frame size of Φ79mm and an input shaft diameter of 8mm and a maximum backlash of 20arcsec.
The HSS series harmonic gearboxes have a flexspline structure in the form of a standard drum and highly rigid, full-roller cross bearings that can be used directly to support external loads and are characterized by high functionality, high speed and high mobility.
The simple structure with high rigidity and low backlash makes it possible to withstand high torques and achieve excellent positioning and rotation accuracy. This harmonic gearbox is widely used in robots, CNC machine tools, textile machines, printing machines, packaging machines and other fields.

Key Feartures

Coaxial Input and Output
Excellent positioning and rotation accuracy
Cup-shaped flexspline and high rigidity full roller cross bearing
LS tooth profile design, high transmission efficiency and low noise
Compact and simple structure design with low to zero backlash, directly connected to the motor and easy to install
Adopting self-developed CMP heat treatment process and 1um trajectory fine grinding with high precision and good reliability

Gearbox Specifications

Part Number: HSS-17-50-I-D8
Gearbox Type: Harmonic Gearbox
Gear Material: Alloy Steel
Gear Ratio: 50:1
Backlash at No-load: <=20arcsec
Rated Torque(Input Speed 2000rpm): 16.00Nm(2265.79oz.in)
Moment Permissible Torque: 70.00Nm(9912.82oz.in)
Peak Start-stop Torque: 34.00Nm(4814.8oz.in)
Maximum Input Speed Allowed: 7300rpm
Average Input Speed Allowed: 3500rpm
Maximum Axial Load: 2.12KN
Maximum Radial Load: 5.3KN
Lifetime: 10000hours

Physical Specifications

Frame Size: Φ79mm
Gearbox Length: 39mm
Input Shaft Type: Keyway
Input Shaft Diameter: Φ8mm

Operating Environment(Tj = 25℃/77℉)

Amient temperature: 0-40℃
No splashing of water or oil
Do not expose to corrosive or explosive gas
No dust such as metal powder

Electrical Specification
Average Input Speed Allowed(rpm)	3500
Rated Torque/2000rpm(Nm)	16.00
Physical Specification
Backlash at No-load	<=20 arcsec
Frame Size(mm)	Φ79
Gear Material	Alloy Steel
Gear Ratio(xx:1)	50
Gearbox Length(mm)	39
Gearbox Type	Harmonic Gearbox
Input Shaft Diameter(mm)	8
IP Rating	65
Product Series	HSS
