Nema 17 External 34mm Stack 0.40A Lead 8mm(0.31496") Length 200mm

0 reviews - Write a review

C$0.00

In Stock: 1
Model: 17E13S0404MB-200RS
Gross Weight: 0.75kg
Certificated: ISO, CE, RoHS

Qty

Add to Cart

Question

Add to Wish List Compare this Product

This product has a minimum quantity of 999

This model is economy linear stepper motor which named Nema 17 external linear actuator with a holding torque of 26Ncm(36.82oz.in), the motor part is 34mm 1.8 degree 0.4A Nema 17 stepper motor. It was integrated with 200mm Tr8x8 threaded rod and a POM screw nut move along the threaded rod.

Electrical Specification

Manufacturer Part Number: 17E13S0404MB-200RS
Motor Type: External Linear Stepper
Step Angle: 1.8deg
Holding Torque: 26Ncm(36.82oz.in)
Rated Current/phase: 0.4A
Phase Resistance: 30ohms
Voltage: 12V
Inductance: 37mH ± 20%(1KHz)

Physical Specification

Frame Size: 42 x 42mm
Body Length: 34mm
Lead Screw Length: 200mm(7.874")
Lead Screw Diameter: Φ8mm(0.315")
Lead/Step:0.04mm(0.0015748")
Lead/Revolution: 8mm(0.315")
Number of Leads: 4
Cable Length: 400mm
Weight: 400g

Connection

A+	A-	B+	B-
Red	Gray	Yellow	Green

Due to some reasons, we have temporarily stopped producing and selling this product. This product cannot be ordered. The alternative product is 17E13S0404MB2-200RS.

Electrical Specification
Bipolar/Unipolar	Bipolar
Has Torque/Thrust Curve?	No
Holding Torque(Ncm)	26
Holding Torque(oz.in)	36.82
Inductance(mH)	37
Phase Resistance(ohms)	30
Rated Current(A)	0.4
Step Angle(deg.)	1.8
Physical Specification
Body Length(mm)	34
Frame Size(mm)	Nema 17 (42 x 42)
Inventory Method	Dedicated Inventory
IP Rating	40
Lead Length(mm)	400
Lead Screw Diameter(mm)	8
Lead Screw Length(mm)	200
Lead Travel/Revolution(mm)	8
Lead Travel/Step(mm)	0.04
Linear Motor Type	External(Acme)
No. of Lead	4
