RSP-200-3.3 MEANWELL 132W 3.3VDC 40A 115/230VAC Single Output With PFC Function

RSP-200-3.3 MEANWELL 132W 3.3VDC 40A 115/230VAC Single Output With PFC Function - RSP-200-3.3 | StepperOnline CA
RSP-200-3.3 MEANWELL 132W 3.3VDC 40A 115/230VAC Single Output With PFC Function - RSP-200-3.3 | StepperOnline CA
RSP-200-3.3 MEANWELL 132W 3.3VDC 40A 115/230VAC Single Output With PFC Function - RSP-200-3.3 | StepperOnline CA
RSP-200-3.3 MEANWELL 132W 3.3VDC 40A 115/230VAC Single Output With PFC Function - RSP-200-3.3 | StepperOnline CA
RSP-200-3.3 MEANWELL 132W 3.3VDC 40A 115/230VAC Single Output With PFC Function - RSP-200-3.3 | StepperOnline CA
RSP-200-3.3 MEANWELL 132W 3.3VDC 40A 115/230VAC Single Output With PFC Function - RSP-200-3.3 | StepperOnline CA
RSP-200-3.3 MEANWELL 132W 3.3VDC 40A 115/230VAC Single Output With PFC Function
0 reviews - Write a review
C$67.03
5 + C$65.06
10 + C$63.23
50 + C$61.48
100 + C$59.82
  • In Stock: Pre-order
  • Brand: MEANWELL
  • Model: RSP-200-3.3
  • Gross Weight: 0.72kg
  • Certificated: ISO, CE, RoHS
Sold: 0

Click country for real-time stock

Add to Cart
Question
Add to Wish List Compare this Product
What Does Pre-order Mean?
A pre-order product is an item not currently in stock. When you place your order, we will begin production or procurement specifically for your purchase.

Features

  • Brand MEANWELL
  • 3.3V DC 40A output
  • AC input voltage range: 88 ~ 264VAC
  • Rated power: 132W
  • Single and two phase wide input range 85~550VAC
  • Universal AC input / Full range
  • Built-in active PFC function
  • High efficiency up to 89%
  • Cooling by free air convection
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Optional conformal coating
  • LED indicator for power on
  • 3 years warranty

Applications

  • Factory control or automation apparatus
  • Test and measurement instrument
  • Laser related machine
  • Burn-in facility
  • RF application
Electrical Specification
Efficiency(%) 81.5%
Max. Output Current(A) 40
Power Supply Specification
Brand MEANWELL
Dim.(LxWxH)(mm) 215 x 115 x 30
Input Frequency(Hz) 47 - 63
Input Voltage(VAC/VDC) 88 - 264 / 124 - 370
Output Voltage(VDC) 3.3
PFC Function Yes
Power Type Switching Power Supply
Power(W) 132
Physical Specification
Inventory Method Shared Inventory
File Size
RSP-200.pdf 862.67KB Download
