CNC Spindle Motor Air Cooled 380V 1.5KW 18000RPM 300Hz ER20 Collet

0 reviews - Write a review

C$241.05

5 + C$234.00

10 + C$227.37

50 + C$221.10

100 + C$215.16

In Stock: 10000
Model: GDZ93x82-1.5C4
Gross Weight: 5.97kg
Certificated: ISO

Sold: 43

Click country for real-time stock

Ships from

China

Qty

Add to Cart

Question

Add to Wish List Compare this Product

Ships within 24 hours!

Ships within 24 hours basically means that your product will be shipped out or dispatched from our warehouse within 24 hours if it has enough stock. Read more.

Choose a Local Warehouse, Get More Benefits!

Customers in US, UK, EU, Australia & Russia: Please choose local warehouses first (German warehouse for EU). This ensures faster delivery and avoids customs duties, reducing total costs.

Specification

Manufacturer Part Number: GDZ93x82-1.5C4
Material: Stainless steel
Size: 137x82(Length: 137mm, Width:82mm)
Power: 1.5KW
Voltage: 380VAC
Current: 3.8A
Frequency: 0 ~ 300Hz
Speed: 0 ~ 18000RPM
Cooling: Air cooled
Bearing Lubrication: Grease
Collet size: ER20 Collet(6mm)
Bearings: 2x7005, 2x7002
Weight: 5.57kg

Operating Environment
Cooling Method	Air cooled
Product Type
Product Type	Spindle Motor
Spindle Motor Specification
Bearing Lubrication	Grease
Body Height(mm)	93
Body Length(mm)	137
Body Width(mm)	82
Collet Size	ER20
Material	Stainless steel
Power(Kw)	1.5
Shape	Square
Voltage(VAC)	380
Electrical Specification
Current(A)	3.8
Frequency(Hz)	0 - 300
Speed(rpm)	0 - 18000
Physical Specification
Bearings	2x7005, 2x7002
Inventory Method	Dedicated Inventory
Weight(Kg)	5.57
