110V AC Gear Motor 40Kg.cm/15RPM w/ 211:1 Rectangular Spur Gearbox
0 reviews - Write a review
C$0.00
  • In Stock: 1
  • Model: FGA-6130-110V-G211
  • Gross Weight: 1.50kg
  • Certificated: ISO, CE
Add to Cart
Question
Add to Wish List Compare this Product
This product has a minimum quantity of 999
Choose a Local Warehouse, Get More Benefits!
Customers in US, UK, EU, Australia & Russia: Please choose local warehouses first (German warehouse for EU). This ensures faster delivery and avoids customs duties, reducing total costs.

This is a standard 110 volt brushed AC gear motor, generating 40kg.cm of torque at 15rpm. It's a small, inexpensive motor suitable for low torque, high speed applications. Combined with a 211 : 1 rectangular gearbox, this motor will provide greater efficiency, higher torque, and quieter motor operation.

Electrical Specification

  • Part Number: FGA-6130-110V-G211
  • Rated Voltage: 110V
  • Rated Torque: 40kg.cm(553.2oz.in)
  • Rated Current: <=850mA
  • Rated Speed: 15rpm
  • No-load Current: <=780mA
  • No-load Speed: 15rpm
  • Rotation Direction: CW
  • Motor Type: Brushed AC Motor

Gearbox Specification

  • Gearbox Type: Rectangular Gearbox
  • Gear Ratio: 211 : 1

Physical Specification

  • Motor Size: 61 x 64 x 30mm
  • Gearbox Size: 95 x 60 x 16mm
  • Front Shaft Diameter: Φ8mm
  • Front Shaft Length: 22mm
  • D-cut Length: 16mm
  • Rear Shaft Diameter: Φ6mm
  • Rear Shaft Length: 12.5mm
Electrical Specification
Rated Current(A) 0.85
Rated Speed(rpm) 15
Rated Torque(kg.cm) 40
Rated Voltage(V) 110
Physical Specification
Gear Ratio(xx:1) 211
Gearbox Shape Rectangular
Gearbox Type Spur Gearbox
Inventory Method Dedicated Inventory
Output Shaft Type D
Shaft Diameter(mm) 8
Shaft Length(mm) 22


File Size
FGA-6130-110V-G211_Full_Datasheet.pdf 160KB Download
