SGD37-33124500-G60
Rated Voltage(V)12
Rated Torque(kg.cm)4.0
Rated Speed(rpm)50
Gearbox TypeSpur Gearbox
Question

Pre-order: A pre-order product is an item not currently in stock. When you place your order, we will begin production or procurement specifically for your purchase.

Ordering & ComplianceFor purchasing
Min. order
20

Downloads

Same series
ModelRated Voltage(V)Rated Speed(rpm)Gearbox TypePriceStock
SGA37-33123000-G9012—24Spur GearboxC$6.79In stock
SGA37-33123000-G90-SALE12—24Spur GearboxC$4.74In stock
SGA37-33126000-G6012—73Spur GearboxC$6.79In stock
SGB37-33123000-G54012—4.4Spur GearboxC$9.50In stock
SGC37-32125000-G9012—50Spur GearboxC$10.16In stock
SGC37-32125000-G90-SALE12—50Spur GearboxC$7.12In stock
SGD37-33124500-G6012—50Spur GearboxC$10.16Backorder
SGE27-27063800-G1876—15Spur GearboxC$6.10Backorder
SGE37-28246000-G18024—25Spur GearboxC$8.47In stock
SGE37-36123000-G54012—4.2Spur GearboxC$10.85Backorder
SGF32-32127000-G7212—80Spur GearboxC$10.16Backorder
SGF37-32127000-G12812—40Spur GearboxC$16.95In stock
Brushed 12V DC Gear Motor 4Kg.cm/50RPM 60:1 Spur Gearbox
This is a standard 12 volt brushed DC gear motor, generating 4kg.cm of torque at 50rpm. It's a small... Read More
from
C$10.16
5 or more: C$9.82
10 or more: C$9.50
50 or more: C$9.19
100 or more: C$8.90

Select a country to see live inventory

Minimum order quantity: 20
Easy Returns

Return within 30 days of delivery. Contact us first and we'll take it from there.

Read more

This is a standard 12 volt brushed DC gear motor, generating 4kg.cm of torque at 50rpm. It's a small, inexpensive motor suitable for low torque, high speed applications. Combined with a 60 : 1 spur gearbox, this motor will provide greater efficiency, higher torque, and quieter motor operation.

Electrical Specification

  • Part Number: SGD37-33124500-G60
  • Rated Voltage: 12V
  • Rated Torque: 4kg.cm(55.32oz.in)
  • Rated Current: <=600mA
  • Rated Speed: 50rpm
  • No-load Current: <=100mA
  • No-load Speed: 75rpm
  • Rotation Direction: CW/CCW
  • Motor Type: Brushed DC Motor

Gearbox Specification

  • Gearbox Type: Spur Gearbox
  • Gear Ratio: 60 : 1

Physical Specification

  • Motor Size: Φ33.1 x 29.1mm
  • Gearbox Size: Φ37 x 22mm
  • Shaft Diameter: Φ6mm
  • Shaft Length: 15.5mm
  • D-cut Length: 12mm
Electrical Specification
Motor Type Brushed DC Motor
Rated Current(A) 0.6
Rated Speed(rpm) 50
Rated Torque(kg.cm) 4.0
Rated Torque(oz.in) 55.32
Rated Voltage(V) 12
Physical Specification
Gear Ratio(xx:1) 60
Gearbox Shape Round
Gearbox Type Spur Gearbox
Output Shaft Type D
Shaft Diameter(mm) 6
Shaft Length(mm) 15.5
