EV200 Series VFD 2HP 1.5KW 7.0A Single Phase 220V Variable Frequency Drive

This is a 2HP 1.5KW 3.8A three phase 380V variable frequency drive. EV200 series high-performance small inverter is a new generation of high-quality, high-reliability small inverter. Based on the needs of small power, small size and simple speed regulation, single-phase 220VAC and three-phase 380VAC small inverters are targetedly launched, which are easy to operate and more cost-effective.

Key Features

• New narrow body design, compact structure layout, smart design, which is conducive to saving installation space and reducing power distribution costs
• Independent air duct, straight up and down, efficient heat dissipation; can be installed side by side, rational use of installation space, greatly reducing the cost of power distribution cabinet
• The keyboard can be external

Key Specification

• Input Voltage: Single Phase 220VAC
• Input Current: 14.0A
• Output Current: 7.0A
• Rated Output Voltage: Three-phase 220VAC
• Output Frequency: 0 - 500Hz
• Power: 2HP(1.5Kw)
• Dimension: 73*143*112.6mm
• Mounting Size: 60*129mm
