CNC Spindle Motor Water Cooled 110V 800W 24000RPM 400Hz ER11 Collet

0 reviews - Write a review

C$126.41

5 + C$122.71

10 + C$119.23

50 + C$115.94

100 + C$112.84

In Stock: Pre-order
Model: GDZ65-800A4
Gross Weight: 3.30kg
Certificated: ISO

Available Options

Ships from

China

Qty

Add to Cart

Question

Add to Wish List Compare this Product

What Does Pre-order Mean?

A pre-order product is an item not currently in stock. When you place your order, we will begin production or procurement specifically for your purchase.

How to Choose a Shipping Warehouse？

For customers in the US, the UK, EU, Australia and Russia, please prioritize selecting a local warehouse. For the EU countries, choose the German warehouse.
The benefits of this selection include faster delivery times and lower overall costs, as no customs duties are incurred.

This s a water-cooled spindle motor with ER11 collet, a power of 800W, a maximum speed of 24000RPM, and a voltage of 110VAC. It mainly matches with variable frequency drives or engraving machines, CNC router machine, and used for high speed profiling, drilling, cutting, engraving and groove milling of wood, metal, plastics, foam, rubber and other materials.

Specification

Manufacturer Part Number: GDZ65-800A4
Material: Stainless steel
Size: Ø65x197(Middle body diameter: 65mm, Length:197mm)
Power: 800W
Voltage: 110VAC
Current: 3.9A
Frequency: 400Hz
Maximum Speed: 24000RPM
Cooling: Water Cooled
Runout off: Less than 0.005mm
Bearing Lubrication: Grease
Collet size: ER11 Collet(3.175mm)
Bearings: 2x7002C(P4 DT) + 2x7000C(P4 DT)
Weight: 3kg

Operating Environment
Cooling Method	Water cooled
Product Type
Product Type	Spindle Motor
Spindle Motor Specification
Bearing Lubrication	Grease
Body Length(mm)	197
Collet Size	ER11
Diameter(mm)	65
Material	Stainless steel
Power(Kw)	0.8
Shape	Round
Voltage(VAC)	110
Electrical Specification
Current(A)	3.9
Frequency(Hz)	0 - 400
Speed(rpm)	0 - 24000
Physical Specification
Bearings	2x7002C(P4 DT), 2x7000C(P4 DT)
Inventory Method	Dedicated Inventory
Weight(Kg)	3
