MH4566-22-22
Body Length(mm)66
Matching Shaft Diameter(mm)22 - 22
Diameter(mm)45
Question

Downloads

MH4566-22-22_Full_Datasheet.pdfPDF · 111.69KB
Same series
ModelBody Length(mm)Matching Shaft Diameter(mm)Diameter(mm)PriceStock
MH2025-5-6255 - 620C$4.73In stock
MH2025-5-6.35255 - 6.3520C$4.73In stock
MH2025-5-8255 - 820C$4.73In stock
MH2025-6-10256 - 1020C$4.73In stock
MH2025-6.35-10256.35 - 1020C$4.73In stock
MH2025-6.35-6.35256.35 - 6.3520C$4.73In stock
MH2025-6.35-8256.35 - 820C$4.73In stock
MH2025-8-10258 - 1020C$4.73In stock
MH2025-8-8258 - 820C$4.73In stock
MH2530-10-123010 - 1225C$5.22In stock
MH2530-6.35-10306.35 - 1025C$5.22In stock
MH2530-6.35-8306.35 - 825C$5.22In stock
MH2530-8-10308 - 1025C$5.22In stock
MH2530-8-12308 - 1225C$5.22In stock
MH2530-8-8308 - 825C$5.22In stock
MH3035-12-143512 - 1430C$5.97In stock
MH3035-14-143514 - 1430C$5.97In stock
MH3035-8-14358 - 1430C$5.97In stock
MH4566-22-226622 - 2245C$16.41In stock
MH5578-22-25.4-SALE7822 - 25.455C$18.46In stock
MH5578-24-247824 - 2455C$21.90In stock
ST-JC02305 - 620C$7.66In stock
ST-JC03305 - 6.3520C$7.66In stock
ST-JC04305 - 820C$7.66In stock
ST-JC06306 - 6.3520C$7.66In stock
ST-JC07306 - 820C$7.66In stock
ST-JC08-SALE306 - 1020C$5.45In stock
ST-JC09306.35 - 6.3520C$7.66In stock
ST-JC11306.35 - 1020C$7.66In stock
ST-JC13308 - 1020C$7.66In stock
View all in category
22mm - 22mm Flexible Jaw Coupling 45x66mm CNC Stepper Motor Shaft Coupler
Specification MPN: MH4566-22-22 Type: Jaw Type Rated Torque: 40Nm(5664.47oz.in) ... Read More
0 reviews • Write a review
from
C$16.41
5 + C$15.60
10 + C$14.88
50 + C$14.20
100 + C$13.59

Click country for real-time stock

Add to Cart
Add to Wish List Compare this Product
Easy Returns

Return within 30 days of delivery. Contact us first and we'll take it from there.

Read more
Ships within 24 hours!
Ships within 24 hours basically means that your product will be shipped out or dispatched from our warehouse within 24 hours if it has enough stock. Read more.

Specification

  • MPN: MH4566-22-22
  • Type: Jaw Type
  • Rated Torque: 40Nm(5664.47oz.in)
  • Max. Torque: 80Nm(11328.93oz.in)
  • Max. Speed: 12000rpm
  • Moment of Inertia: 2.6*10-3kg*m2
  • Static Torsional Spring Constant: 800Nm/rad
  • Bore Diameter(d1-d2): 22mm - 22mm
  • Body Outside Diameter(D): 45mm
  • Body Length(L): 66mm
  • Material Type: Aluminum
  • Weight: 196g
Coupling Specification
Coupling Type Jaw Shaft Coupling
Body Length(mm) 66
Diameter(mm) 45
Matching Shaft Diameter(mm) 22 - 22
