ERP-200-24 MEANWELL 199.92W 8.33A 230VAC Single Output Switching Power Supply
0 reviews - Write a review
C$42.92
5 + C$41.66
10 + C$40.48
50 + C$39.37
100 + C$38.30
  • In Stock: Pre-order
  • Brand: MEANWELL
  • Model: ERP-200-24
  • Gross Weight: 0.86kg
  • Certificated: ISO, CE, RoHS
Sold: 0

Click country for real-time stock

Add to Cart
Question
Add to Wish List Compare this Product
What Does Pre-order Mean?
A pre-order product is an item not currently in stock. When you place your order, we will begin production or procurement specifically for your purchase.

Features

  • Brand MEANWELL
  • 24V DC 8.33A output
  • AC input voltage range: 180 ~ 264VAC
  • Rated power: 199.92W
  • Withstand 300VAC surge input for 5 seconds
  • Design against rain splash
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Cooling by free air convection
  • LED indicator for power on
  • Low cost, high reliability
  • 100% full load burn-in test
  • 3 years warranty

Applications

  • LED strip lighting
  • LED channel letters
  • LED display
Electrical Specification
Efficiency(%) 89%
Max. Output Current(A) 8.33
Power Supply Specification
Brand MEANWELL
Dim.(LxWxH)(mm) 200 x 120 x 40
Input Frequency(Hz) 47 - 63
Input Voltage(VAC/VDC) 180 - 264 / 254 - 370
Output Voltage(VDC) 24
PFC Function No
Power Type Switching Power Supply
Power(W) 199.92
Physical Specification
Inventory Method Shared Inventory
File Size
ERP-200.pdf 689.8KB Download
