UHP-1500-115 MEANWELL 1500.75W 13.05A 115/230VAC Slim Type With PFC Switching Power Supply
0 reviews - Write a review
C$613.79
5 + C$595.86
10 + C$578.96
50 + C$562.99
100 + C$547.88
  • In Stock: 10000
  • Brand: MEANWELL
  • Model: UHP-1500-115
  • Gross Weight: 2.51kg
  • Certificated: ISO, CE, RoHS
Sold: 1

Click country for real-time stock

Add to Cart
Question
Add to Wish List Compare this Product
Ships within 24 hours!
Ships within 24 hours basically means that your product will be shipped out or dispatched from our warehouse within 24 hours if it has enough stock. Read more.
Choose a Local Warehouse, Get More Benefits!
Customers in US, UK, EU, Australia & Russia: Please choose local warehouses first (German warehouse for EU). This ensures faster delivery and avoids customs duties, reducing total costs.

Features

  • Brand MEANWELL
  • 115V DC 13.05A output
  • AC input voltage range: 90 ~ 264VAC
  • Rated power: 1500.75W
  • Hign voltage output(115/230/380V)
  • Fanless design and conduction-cooled design
  • Slim and 1U Low profile(41mm)
  • Built-in active PFC function
  • DC 12V/04A auxiliary power
  • Output voltage and constant current level programmable(PV/PC)
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Built-in remote ON-OFF control and DC OK signal
  • Operating altitude up to 2000 meter(E type Note.6, Blank/PM/CAN type Note.7)
  • LED indicator for power on
  • Optional PMBus or CANBus protocol
  • 5 years warranty

Applications

  • Industrial automation machinery
  • Industrial control system
  • Mechanical and electrical equipment
  • Electronic instruments, equipments or apparatus
  • Test and measurement instruments
  • Laser related machine
  • Charging related equipment
  • DC centralized bus(Lighting)
Electrical Specification
Efficiency(%) 95%
Max. Output Current(A) 13.05
Power Supply Specification
Brand MEANWELL
Dim.(LxWxH)(mm) 290 x 140 x 41
Input Frequency(Hz) 47 - 63
Input Voltage(VAC/VDC) 90 - 264 / 250 - 370
Output Voltage(VDC) 115
PFC Function Yes
Power Type Switching Power Supply
Power(W) 1500.75
Physical Specification
Inventory Method Dedicated Inventory
File Size
UHP-1500.pdf 700.79KB Download
