P Series Nema 23 1.2deg 3-phase Stepper Motor 5.5A 1Nm(141.64oz.in)

0 reviews - Write a review

C$32.83

5 + C$31.27

10 + C$29.87

50 + C$28.59

100 + C$27.41

In Stock: 10000
Model: 23HT22-5503S
Gross Weight: 0.77kg
Certificated: ISO, CE, UKCA, RoHS

Sold: 399

Click country for real-time stock

Ships from

China

Qty

Add to Cart

Question

Add to Wish List Compare this Product

Ships within 24 hours!

Ships within 24 hours basically means that your product will be shipped out or dispatched from our warehouse within 24 hours if it has enough stock. Read more.

Choose a Local Warehouse, Get More Benefits!

Customers in US, UK, EU, Australia & Russia: Please choose local warehouses first (German warehouse for EU). This ensures faster delivery and avoids customs duties, reducing total costs.

Electrical Specification

Manufacturer Part Number: 23HT22-5503S
Number of phase: 3
Step Angle: 1.2deg
Holding Torque: 1Nm(141.64oz.in)
Rated Current/phase: 5.5A
Phase Resistance: 0.45ohms
Inductance: 0.98mH±20%(1KHz)
Insulation Class: B 130°C[266°F]

Physical Specification

Frame Size: 57 x 57mm
Body Length: 55.5mm
Shaft Diameter: Φ8mm
Shaft Length: 21mm
D-Cut Shaft Length: 15mm
Lead Length: 500mm
Weight: 0.72kg

Connection

U	V	W
Green	Red	Blue

Product Type
Product Type	3-phase stepper motor
Electrical Specification
Has Torque/Thrust Curve?	Yes
Holding Torque(Ncm)	100
Holding Torque(oz.in)	141.64
Inductance(mH)	0.98
Insulation Class	B 130C(266F)
No. of Phase	3
Open-loop/Closed-loop	Open-loop
Phase Resistance(ohms)	0.45
Rated Current(A)	5.5
Step Angle(deg.)	1.2
Physical Specification
Body Length(mm)	55.5
Frame Size(mm)	Nema 23 (57 x 57)
Inventory Method	Dedicated Inventory
Lead Length(mm)	500
No. of Lead	3
Output Shaft Type	D
Product Series	S
Shaft Diameter(mm)	8
Shaft Length(mm)	21
Single Shaft/Dual Shaft	Single Shaft
Weight(g)	720
