Name: RSP-3000-24 | RSP-3000-24 MEANWELL 3000W 24VDC 125A 180/230VAC Power Supply With Single Output | StepperOnline CA
Brand: MEANWELL
SKU: RSP-3000-24
Price: 1033.26 CAD
Availability: PreOrder

RSP-3000-24 MEANWELL 3000W 24VDC 125A 180/230VAC Power Supply With Single Output

0 reviews - Write a review

C$1,033.26

5 + C$1,003.10

10 + C$974.64

50 + C$947.75

100 + C$922.31

In Stock: Pre-order
Brand: MEANWELL
Model: RSP-3000-24
Gross Weight: 4.00kg
Certificated: ISO, CE, RoHS

Available Options

Ships from

China

Qty

Add to Cart

Question

Add to Wish List Compare this Product

What Does Pre-order Mean?

A pre-order product is an item not currently in stock. When you place your order, we will begin production or procurement specifically for your purchase.

How to Choose a Shipping Warehouse？

For customers in the US, the UK, EU, Australia and Russia, please prioritize selecting a local warehouse. For the EU countries, choose the German warehouse.
The benefits of this selection include faster delivery times and lower overall costs, as no customs duties are incurred.

Ships within 24 hours!

Ships within 24 hours basically means that your product will be shipped out or dispatched from our warehouse within 24 hours if it has enough stock. Read more.

Features

Brand MEANWELL
24V DC 125 output
AC input voltage range: 180 ~ 264VAC
Rated power: 3000W
Built-in active PFC function
High efficiency up to 91.5%
Forced air cooling by built-in DC Fan
Output voltage and constant current level programmable
Active current sharing up to 7200W(2+1)
Built-in remote ON-OFF control / remote sense / auxiliary power / DC OK signal / OTP alarm signal
Protections: Short circuit / Overload / Over voltage / Over temperature
Optional PMBus or CANBus protocol
5 years warranty

Applications

Factory control or automation apparatus
Test and measurement instrument
Laser related machine
Digital broadcasting
Burn-in facility
RF application

Electrical Specification
Efficiency(%)	90%
Max. Output Current(A)	125
Power Supply Specification
Brand	MEANWELL
Dim.(LxWxH)(mm)	278 x 177.8 x 63.5
Input Frequency(Hz)	47 - 63
Input Voltage(VAC/VDC)	180 - 264 / 254 - 370
Output Voltage(VDC)	24
PFC Function	Yes
Power Type	Switching Power Supply
Power(W)	3000
Physical Specification
Inventory Method	Shared Inventory
