Square Spindle Motor Air Cooled 380V 4.5KW 18000RPM 300Hz ER32 Collet CNC Machine
0 reviews - Write a review
C$0.00
  • In Stock: 1
  • Model: GDZ120x103-4.5C4
  • Gross Weight: 12.90kg
  • Certificated: ISO
Sold: 27
Add to Cart
Question
Add to Wish List Compare this Product
This product has a minimum quantity of 999
Choose a Local Warehouse, Get More Benefits!
Customers in US, UK, EU, Australia & Russia: Please choose local warehouses first (German warehouse for EU). This ensures faster delivery and avoids customs duties, reducing total costs.

Specification

  • Manufacturer Part Number: GDZ120x103-4.5C4
  • Material: Stainless steel
  • Size: 191x103(Length: 191 mm, Width:103 mm)
  • Power: 4.5 KW
  • Voltage: 380 VAC
  • Current: 9.5 A
  • Frequency: 0 ~ 300 Hz
  • Speed: 0 ~ 18000 RPM
  • Cooling: Air cooled
  • Runout off: Less than 0.005 mm
  • Bearing Lubrication: Grease
  • Collet size: ER32 Collet(6 mm, 12.7 mm)
  • Bearings: 2x7008C(P4), 2x7004C(P4)
  • Weight: 12.4 kg

Resources

Operating Environment
Cooling Method Air cooled
Spindle Motor Specification
Bearing Lubrication Grease
Body Height(mm) 120
Body Length(mm) 191
Body Width(mm) 103
Collet Size ER32
Material Stainless steel
Power(Kw) 4.5
Shape Square
Voltage(VAC) 380
Electrical Specification
Current(A) 9.5
Frequency(Hz) 0 - 300
Speed(rpm) 0 - 18000
Physical Specification
Bearings 2x7008C(P4), 2x7004C(P4)
Weight(Kg) 12.4
File Size
GDZ120103-4.5C4_Full_Datasheet.pdf 93.96KB Download
