4.3" 480x272px RS-485 Serial port & USB 128MB/FLASH 128MB/Memory HMI Touch Screen LED Display
0 reviews - Write a review
C$0.00
  • In Stock: 1
  • Model: HI3043ig-C
  • Gross Weight: 1.30kg
  • Certificated: ISO
Sold: 4
Add to Cart
Question
Add to Wish List Compare this Product
This product has a minimum quantity of 999
Choose a Local Warehouse, Get More Benefits!
Customers in US, UK, EU, Australia & Russia: Please choose local warehouses first (German warehouse for EU). This ensures faster delivery and avoids customs duties, reducing total costs.

This high-end 4.3-inch HMI touch screen display features an LED screen with 480x272 pixel resolution and 300cd/m² brightness. The backlit LED display offers excellent visibility, with a lifespan exceeding 20,000 hours. Compared to standard ones, this touchscreen includes USB 2.0 and two USB Type-C interfaces for enhanced debugging and control. Compliant with IP65 flat panel installation standards, the panel is ideal for various PLCs or intelligent controllers equipped with communication ports. Users can easily design and create programs using the included intuitive and powerful software.

Specifications

  • Part Number: HI3043ig-C
  • Display Type: HMI Display
  • Processor: 4-core high-performance CPU
  • Storage: 128MB NAND FLASH + 128MB Memory
  • Operating Voltage: 24VDC
  • Display Resolution: 480x272px
  • Display Brightness: 300cd/m²
  • Display Backlight: LED
  • Display Size: 4.3"
  • Panel Cut-out: 131.0x78.0mm
  • Backlight Lifetime: 20,000 hours
  • USB Port: USB 2.0/USB TYPE-C Note: Two USB ports cannot be used simultaneously.
  • Ethernet: Yes
  • I/O Port: Serial port(9): (RS-232, RS-422/RS-485, RS-485)

Downloads

Electrical Specification
Has Ethernet? Yes
Has IIoT? No
Operating Voltage(V) 24
WIFI Enabled No
Physical Specification
Backlight Lifetime(h) 20000
Display Brightness(cd/m²) 300
Display Resolution(Pixels) 480x272
Display Size(inch) 4.3
Panel Cut-out(mm) 131.0x78.0
Processor 4-core high-performance CPU
Storage 128MB NAND FLASH + 128MB Memory
