Nema 23 Integrated Stepper Motor 300Ncm(425oz.in) w/ Driver ISD08 12-38VDC

0 reviews - Write a review

C$128.02

5 + C$123.64

10 + C$119.55

50 + C$115.72

100 + C$112.14

In Stock: Pre-order
Model: ISD08-30
Gross Weight: 1.90kg
Certificated: ISO, CE

Sold: 49

Click country for real-time stock

Ships from

China

Qty

Add to Cart

Question

Add to Wish List Compare this Product

This product has a minimum quantity of 10

What Does Pre-order Mean?

A pre-order product is an item not currently in stock. When you place your order, we will begin production or procurement specifically for your purchase.

Electrical Specifications

Manufacturer Part Number: ISD08-30
Step Angle: 1.8deg
Holding Torque: 300Ncm(425oz.in)
Rated Current/phase: 4.2A
Phase Resistance: 0.9ohms
Inductance: 3.8mH ± 20%(1KHz)

Physical Specifications

Frame Size: 57 x 57mm
Body Length: 133mm
Shaft Diameter: Φ10mm
Shaft Length: 24mm
Weight: 1850g

Driver Specifications

Output Peak Current: 3 - 8A
Input Voltage: 12 - 38VDC
Insulation Class: B 130°C[266°F]
Speed control through external potentiometer 0. 75 - 1250RPM
Isolation Resistance: More than 100MΩ
Dielectric strength: 500VAC for 1MIN.

Connection

V+	GND	VCC	DIR	STP	ENA
Red	Black	White	Green	Purple	Blue

Product Type
Product Type	Integrated Stepper Motor
Electrical Specification
Analog Input	No
Control Modes	Pulse Mode
Encoder Feedback	No (Open Loop)
Holding Torque(Ncm)	300
Holding Torque(oz.in)	425
Input Voltage Reference(V)	12 - 36DC
Input Voltage(V)	10 - 40DC
Physical Specification
Body Length(mm)	133
Frame Size(mm)	Nema 23 (57 x 57)
Inventory Method	Dedicated Inventory
Shaft Diameter(mm)	10
Shaft Length(mm)	24
